Mechanical dial gauge SI-45, 0.4/4.5/0.01 mm, Ø40 mm

Error free dial gauge

Mechanical dial gauge SI-45, 0.4/4.5/0.01 mm, Ø40 mm
€ 73.50 *Prices are exclusive of VAT
Article code:  10005
Error free dial gauge: in order to avoid reading errors the measuring range of these dial gauges is limited to slightly less than one revolution of the pointer. Therefore a measurement can only be performed within the range of one revolution of the hand guaranteeing error free reading of the dial gauge.
  • reading: 0.01 mm
  • overtravel: 4.5 mm
  • range: 0.4 mm
  • graduation: 20~0~20
  • initial measuring force: 1 N
  • Ø bezel: 40 mm
  • Ø stem: 8h6
  • metal casing, bezel made of polyamide
  • rotating dial
  • flat back (removable)
  • stem and spindle made of resistant stainless steel
  • protection category: IP40
  • dimensions: according to DIN EN ISO 463
  • accuracy: according to DIN 878
  • weight: 104 g
  • delivered in box with removable standard contact point, steel Ø 3 mm, M2,5

Options and special fittings
  • calibration certificate
  • tolerance indicators
  • back: magnetic, lug or special

Option

Lug back vertical for dial gauges Ø40 mm, bore Ø5 mm

Lug back vertical for dial gauges Ø40 mm, bore Ø5 mm
Accessorie

€ 4.80
Magnetic back for dial gauges Ø40 mm

Magnetic back for dial gauges Ø40 mm
Accessorie

€ 50.50
Lug back horizontal for dial gauges Ø40 mm, bore Ø5 mm

Lug back horizontal for dial gauges Ø40 mm, bore Ø5 mm
For waterproof dial gage W

€ 28.80
Horizontal prism back for dial gauges Ø40 mm

Horizontal prism back for dial gauges Ø40 mm
Accessorie

€ 14.40
Vertical prism back for dial gauges Ø40 mm

Vertical prism back for dial gauges Ø40 mm
Accessorie

€ 14.40
Factory certificate DIN 878 dial gauge, 0.01 mm, >5~10 mm

Factory certificate DIN 878 dial gauge, 0.01 mm, >5~10 mm
Option

€ 11.35
